The H.F. Preheating process is widely applied for Thermo-set plastic moulding. In the FRP pultruction and SMC/BMC moulding process, H.F. Pre-heaters are also developingly used.
Usage:
Melamine resin, Urea moulding compund, bakelite, Phenolic Resin, epoxy resin and thermosetting moluding compound, fiber and heated compression material products.
5KW
7KW
10KW
SPECIFICATIONS | FLAT ELECTRODE |
MODEL | DMP-520S |
OUTPUT | 5KW |
POWER SOURCE | 480V3P |
POWER INPUT | 11KVA |
OSCILLATION FREQUENCY | 62MHZ |
OSCILLATION TUBE | 7T69RB |
VOLTAGE SWITCHING | 3-STAGE |
TIMER | 0-999.9 S |
ARRANGEMENT OF HOOD | MOTOR TYPE AUTOMATIC OPENING AND CLOSING |
PREHEATING POWER | 110°C WINTHIN 80 SECS. |
PHENOILC RESIN | 1200G |
MELAMINE RESIN | 1000G |
UREA MOULDING COMPUND | 1500G |
ELECTRODE SIZE | 310×360M/M |
ELECTRODE SPACING | 30-70M/M |
WEIGHT | 250KG |
SPECIFICATIONS | FLAT ELECTRODE |
MODEL | DMP-720S |
OUTPUT | 7KW |
POWER SOURCE | 480V3P |
POWER INPUT | 13KVA |
OSCILLATION FREQUENCY | 62MHZ |
OSCILLATION TUBE | E3069 |
VOLTAGE SWITCHING | 3-STAGE |
TIMER | 0-999.9 S |
ARRANGEMENT OF HOOD | MOTOR TYPE AUTOMATIC OPENING AND CLOSING |
PREHEATING POWER | 110°C WINTHIN 80 SECS. |
PHENOILC RESIN | 1500G |
MELAMINE RESIN | 1400G |
UREA MOULDING COMPUND | 1800G |
ELECTRODE SIZE | 350×380M/M |
ELECTRODE SPACING | 30-70M/M |
WEIGHT | 260KG |
SPECIFICATIONS | FLAT ELECTRODE |
MODEL | DMP-1020S |
OUTPUT | 10KW |
POWER SOURCE | 480V3P |
POWER INPUT | 20KVA |
OSCILLATION FREQUENCY | 27MHZ |
OSCILLATION TUBE | E3130 |
VOLTAGE SWITCHING | 1-STAGE |
TIMER | 0-999.9 S |
ARRANGEMENT OF HOOD | MOTOR TYPE AUTOMATIC OPENING AND CLOSING |
PREHEATING POWER | 110°C WINTHIN 80 SECS. |
PHENOILC RESIN | 2500G |
MELAMINE RESIN | 2500G |
UREA MOULDING COMPUND | 2800G |
ELECTRODE SIZE | 450×560M/M |
ELECTRODE SPACING | 35-80M/M |
WEIGHT | 600KG |
