Hydraulic Compression Moulding Machine

Compression moulding is composed of heated moulds by hot platens and proper clamping force. With valves and pump dominated by PLC, the machines complete precise movement, such as pressing, drain air, etc.

The mould is closed with a top force or plug member, pressure is applied to force the material into contact with all mould areas, while heat and pressure are maintained until the moulding material has cured.

The process employs thermosetting resins in a partially cured stage, either in the form of granules putty-like masses, or preforms. Compression moulding is a high-volume, high-pressure method suitable for moulding complex, high-strength fiberglass reinforcements.

Usage:

Melamine tablewares, bakelite products, and UREA products

GET A QUOTE

Features:

High performance

Noiseless operation

Facilitates automatic centralized lubrication

Specifications:

200 Ton Hydrolic Press

300 Ton Hydrolic Press

200 Ton
300 Ton

SPEC/MODEL	TP-200
CLAMPING FORCE(TON)	238
PLATEN SIZE W*D(MM)	760*650
DIAMETER OF PISTON(MM)	380
STROKE(MM)	480
DAYLIGHT(MM)	700
PUMP MAX PRESSURE(KG/CM2)	210
MOTOR 6P(HP/KW)	10 / 7.5
HEATER POWER(KW)	10.8
TOTAL POWER CAPACITY(KW)	18.3
OIL TANK CAPACITY(L)	480
MACHINE DIMENSION WDH(M)	2.11.352.3
NET WEIGHT(KG)	4800

SPEC/MODEL	TP-300
CLAMPING FORCE(TON)	349
PLATEN SIZE W*D(MM)	900*740
DIAMETER OF PISTON(MM)	460
STROKE(MM)	480
DAYLIGHT(MM)	700
PUMP MAX PRESSURE(KG/CM2)	210
MOTOR 6P(HP/KW)	15/11
HEATER POWER(KW)	14.4
TOTAL POWER CAPACITY(KW)	25.9
OIL TANK CAPACITY(L)	570
MACHINE DIMENSION WDH(M)	2.31.62.66
NET WEIGHT(KG)	7100
